Features
1. Used for processing lock-holes and grooves on aluminum windows and doors.
2. Copy-routing processing is available.
3. It can realize horizontal drilling of three holes and vertical copy routing of long holes.
Parameters
| Model | SZS-100 |
| Power | 1.5KW+0.75KW |
| Rotary Speed | 2850rpm/min |
| Voltage | 380V/50HZ |
| Air Pressure | 0.5-0.8Mpa |
| Milling Cutter Diameter | 5mm,8mm |
| Copy Dimension | 290x90 |
| Dimension | 1000x1100x1500mm |
Detailed Pictures
